(Option A) Best quality - HDMI connection (includes audio and video)

If you have a HDMI TV or monitor, you can connect it to this recorder using a HDMI cable H. Connect the HDMI jack on

the recorder to the HDMI jack on a HDMI compatible TV or monitor. Set the TV’s source to HDMI (refer to TV’s Owner’s

manual).

l You must select a HDMI audio output and a maximum sampling frequency that your TV accepts using [Digital Output]

option on the [Setup] menu (see page 46).

l If a connected HDMI device does not accept the audio output of the recorder, the HDMI device’s audio sound may be

distorted or may not output.

l When you use HDMI connection, you can change the resolution for the HDMI output by pressing RESOLUTION

button in TV watching mode or in Home Menu mode.

Caution

l Changing the resolution when the connection has already been established may result in malfunctions. To solve the

problem, turn off the recorder and then turn it on again.

l When the HDMI connection with HDCP is not verified, TV screen is changed to black screen. In this case, check the

HDMI connection, or disconnect the HDMI cable.

l If there is noise or lines on the screen, please check the HDMI cable (length is generally limited to 4.5m).

Additional Information for HDMI

l When you connect a HDMI or DVI compatible device make sure of the following:

- Try switching off the HDMI/DVI device and this recorder. Next, switch on the HDMI/DVI device and leave it for around

30 seconds, then switch on this recorder.

- The connected device’s video input is set correctly for this Recorder.

- The connected device is compatible with 720x576p, 1280x720p, 1920x1080i or 1920x1080p video input.

l Not all HDCP-compatible HDMI or DVI devices will work with this recorder.

- The picture will not be displayed properly with non-HDCP device.

- This recorder does not playback and TV screen is changed to black screen.
