www.lg.comOWNER’S MANUALLED TV23MA73D27MA73DPlease read this manual carefully before operating the your TV and retain it for future reference.LG LED T

ENGLISH10ASSEMBLING AND PREPARINGWhen holding the TV, the screen should face away from you to prevent the screen from scratches. When transporting

ENGLISH11ASSEMBLING AND PREPARING2 Attach the Stand Base from the Stand Body by turning the screw to the right with a Coin.Setting up the TVAttaching

ENGLISH12ASSEMBLING AND PREPARINGCAUTIONDo not carry the monitor upside-down by holding the stand body as this may cause it to fall off, resulting i

ENGLISH13ASSEMBLING AND PREPARINGMounting on a table1 Lift and tilt the TV into its upright position on a table.Leave a 10 cm (4 inches) (minimum) sp

ENGLISH14ASSEMBLING AND PREPARINGTidying cablesUsing the Kensington security system The Kensington security system connector is located at the back of

ENGLISH15ASSEMBLING AND PREPARING2 Pull out the Stand Body from the TV.Detaching the Stand1 Place the TV with the screen side down on a flat and cus

ENGLISH16ASSEMBLING AND PREPARING5 Please use VESA standard as below.784.8 mm (30.9 inch) and under* Wall Mount Pad Thickness : 2.6 mm* Screw : Φ 4

ENGLISH17ASSEMBLING AND PREPARINGDisconnect the power cord first, and then move or install the TV. Otherwise electric shock may occur.If you insta

ENGLISH18WATCHING TVTurning the TV on for the first timeWhen you access the TV for the first time, the initial setting screen appears. Select a langua

ENGLISH19WATCHING TVFor those countries without confirmed DTV broadcasting standards, some DTV features might not work, depending on the DTV broadca

2ENGLISHTABLE OF CONTENTSTABLE OF CONTENTS3 LICENSES4 INSTALLATION PROCEDURE5 ASSEMBLING AND PREPARING5 Unpacking8 Parts and buttons10 Lifting a

ENGLISH20MAKING CONNECTIONSConnect various external devices to the TV and switch input modes to select an external device. For more information about

ENGLISH21MAKING CONNECTIONSOutdoor AntennaVHF AntennaUHF AntennaConnecting to a HD receiver, DVD, VCR player or Gaming deviceConnect a HD receiver

ENGLISH22MAKING CONNECTIONSHDMI to DVI connectionTransmits the digital video signal from an external device to the TV. Connect the external device and

ENGLISH23MAKING CONNECTIONSComponent connectionTransmits the analog video and audio signals from an external device to the TV. Connect the external de

ENGLISH24MAKING CONNECTIONSComposite connectionTransmits the analog video and audio signals from an external device to the TV. Connect the external de

ENGLISH25MAKING CONNECTIONSEuro Scart connectionTransmits the video and audio signals from an external device to the TV. Connect the external device a

ENGLISH26MAKING CONNECTIONSHeadphone connectionTransmits the headphone signal from the TV to an external device. Connect the TV with the headphone as

ENGLISH27MAKING CONNECTIONSConnecting to a USBConnect a USB storage device such as s USB flash memory, external hard drive, MP3 player or a USB memory

ENGLISH28MAKING CONNECTIONSAV 1AV2 IN(PC)(MONO)MHL connectionMobile High-definition Link (MHL) is an interface for transmitting digital audiovisual si

ENGLISH29MAKING CONNECTIONSConnecting to a PCYour TV supports the Plug & Play* feature and has the built-in speakers with Virtual Surround that re

ENGLISH3LICENSESLICENSESSupported licenses may differ by model. For more information of the licenses, visit www.lg.com.Manufactured under license from

ENGLISH30MAKING CONNECTIONSHDMI connectionTransmits the digital video and audio signals from your PC to the TV. Connect the PC and the TV with the HDM

ENGLISH31MAKING CONNECTIONSHDMI to DVI connectionTransmits the digital video signal from your PC to the TV. Connect the PC and the TV with the HDMI to

ENGLISH32MAKING CONNECTIONSRGB connectionTransmits the analog video signal from your PC to the TV. Connect the PC and the TV with the D-sub 15 pin cab

ENGLISH33REMOTE CONTROLThe descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the T

ENGLISH34REMOTE CONTROLOn MHEG channel, you cannot adjust the backlight with the yellow or blue key.NOTETV/PCSelects TV or PC mode.EXITClears all on-s

ENGLISH35CUSTOMIZING SETTINGSCUSTOMIZING SETTINGSAccessing main menus1 Press SETTINGS to access the main menus.2 Press the Navigation buttons to scr

ENGLISH36 USING THE USER GUIDE USING THE USER GUIDE Accessing User Guide menu.Using the TV menu1 Press SETTINGS to access the main menus.2 Press the

ENGLISH37MAINTENANCEMAINTENANCECleaning Your TVClean your TV regularly to keep the best performance and to extend the product lifespan.Screen and fram

ENGLISH38MAINTENANCEIf a fixed image displays on the TV screen for a long period of time, it will be imprinted and become a permanent disfigurement

ENGLISH39TROUBLESHOOTINGTROUBLESHOOTINGGeneralProblem ResolutionCannot control the TV with the remote control. Check the remote control sensor on the

ENGLISH4INSTALLATION PROCEDUREINSTALLATION PROCEDURE1 Open the package and make sure all the accessories are included.2 Attach the stand to the TV.3

ENGLISH40SPECIFICATIONSSPECIFICATIONS 23MA73D Panel Screen Type 580 mm Wide (23 inch)Visible diagonal size : 580 mmPixel Pitch 0.265 mm (H) x 0.265 mm

ENGLISH41SPECIFICATIONSPanel Screen Type 690 mm Wide (27 inch)Visible diagonal size : 690 mmPixel Pitch 0.3114 mm (H) x 0.3114 mm (V)Video Signal Max.

ENGLISH42SPECIFICATIONSComponent supported modeResolution HorizontalFrequency(kHz)VerticalFrequency(Hz)720 x 480 15.730 59.940720 x 480 15.750 60.0007

ENGLISH43SPECIFICATIONS NOTEAvoid keeping a fixed image on the set’s screen for prolonged periods of time. The fixed image may become permanently im

Make sure to read the Safety Precautions before using the product.Keep the Owner’s Manual (CD) in an accessible place for future reference.The model a

ENGLISH5ASSEMBLING AND PREPARINGASSEMBLING AND PREPARINGUnpackingCheck your product box for the following items. If there are any missing accessories,

ENGLISH6ASSEMBLING AND PREPARINGRemote controlBatteries (AAA)Power CordStand BaseCD (Owner's Manual).CardsStand BodyCable Holder(See p.33, See p.

ENGLISH7ASSEMBLING AND PREPARING NOTE Antenna Isolator Installation Guide -Use this to install TV in a place where there is a voltage difference betw

ENGLISH8ASSEMBLING AND PREPARINGParts and buttonsAll of the buttons are touch sensitive and can be operated through simple touch with your finger.Powe

ENGLISH9ASSEMBLING AND PREPARING(PC)AV 1AV 2 IN(MONO)Connection panel (See p.20)
